Threaded Smoothline Forks
Available Variations:
Handedness: Left Hand-L or Right Hand-RClick part row for purchase options.
| SKU | Name | A | ØPin | Thread Size | |||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| mm | Inch | mm | Inch | UNF | TPI | ||||||
| SLTF08 | Threaded Smoothline Fork 1/4" | 8.0 | 5/16 | 6.5 | 1/4 | 0.3 | 28.0 | ||||
| SLTF10 | Threaded Smoothline Fork 5/16" | 8.0 | 5/16 | 6.5 | 1/4 | 0.3 | 24.0 | ||||
Part numbers in 1/32"
CAUTION
- If DYFORM or HAMMA wire is used then select fittings for one wire size bigger. These fittings are available on request.
- Maximum Working Loading = 40% of Breaking Strength.
