Lifeline Closed Turnbuckle, Smoothline Fork-Stud
Available Variations:
Finish: Chrome-C or Bronze-BClick part row for purchase options.
| SKU | Name | Wire Size | Body Thread | W | ØPin | A | B | C -Wire Depth | |||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| mm | Inch | UNF | mm | Inch | mm | Inch | mm | Inch | mm | Inch | mm | ||||||
| CBSLF0408 | Lifeline Closed Turnbuckle, Smoothline Fork-Stud 1/4", 3mm Stud | 3.0 | 1/8 | 1/4 | 8.0 | 5/16 | 6.5 | 1/4 | 96.0 | 3 25/32 | 56.0 | 2.205 | 32.0 | ||||
| CBSLF0410 | Lifeline Closed Turnbuckle, Smoothline Fork-Stud 5/16", 3mm Stud | 3.0 | 1/8 | 5/16 | 8.0 | 5/16 | 6.5 | 1/4 | 96.0 | 3 25/32 | 61.0 | 2 13/32 | 32.0 | ||||
| CBSLF0508 | Lifeline Closed Turnbuckle, Smoothline Fork-Stud 1/4", 4mm Stud | 4.0 | 5/32 | 1/4 | 8.0 | 5/16 | 6.5 | 1/4 | 100.0 | 3 30/32 | 56.0 | 2.205 | 32.0 | ||||
| CBSLF0510 | Lifeline Closed Turnbuckle, Smoothline Fork-Stud 5/16", 4mm Stud | 4.0 | 5/32 | 5/16 | 8.0 | 5/16 | 6.5 | 1/4 | 108.0 | 4 1/4 | 61.0 | 2 13/32 | 32.0 | ||||
| CBSLF0608 | Lifeline Closed Turnbuckle, Smoothline Fork-Stud 1/4", 5mm Stud | 5.0 | 3/16 | 1/4 | 8.0 | 5/16 | 6.5 | 1/4 | 100.0 | 3 30/32 | 56.0 | 2.205 | 32.0 | ||||
| CBSLF0610 | Lifeline Closed Turnbuckle, Smoothline Fork-Stud 5/16", 5mm Stud | 5.0 | 3/16 | 5/16 | 8.0 | 5/16 | 6.5 | 1/4 | 108.0 | 4 1/4 | 61.0 | 2 13/32 | 32.0 | ||||
Part numbers in 1/32"
CAUTION
- If DYFORM or HAMMA wire is used then select fittings for one wire size bigger. These fittings are available on request.
- Maximum Working Loading = 40% of Breaking Strength.
