Architectural Swage Stud
Available Variations:
Units: Metric-M or Imperial-IClick part row for purchase options.
| SKU | Name | Wire Size | Body Body Thread | A | B | C | ||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| mm | Inch | UNF | mm | Inch | mm | Inch | mm | Inch | ||||||
| ASS04-1-4 | Architectural Swage Stud 3mm Stud With 1/4" | 3.0 | 1/8 | 1/4 | 76.0 | 2.000 | 32.0 | 1 1/4 | 36.0 | 1 13/32 | ||||
| ASS05-1-4 | Architectural Swage Stud 4mm Stud With 1/4" | 4.0 | 5/32 | 1/4 | 76.0 | 2.000 | 32.0 | 1 1/4 | 36.0 | 1 13/32 | ||||
| ASS06-1-4 | Architectural Swage Stud 5mm Stud With 1/4" | 5.0 | 3/16 | 1/4 | 76.0 | 2.000 | 32.0 | 1 1/4 | 36.0 | 1 13/32 | ||||
Part numbers in 1/32"
CAUTION
- If DYFORM or HAMMA wire is used then select fittings for one wire size bigger. These fittings are available on request.
- Maximum Working Loading = 40% of Breaking Strength.
