Lifeline Swage Stud



Available Variations:

Handedness: Left Hand-L or Right Hand-R
Units: Metric-M or Imperial-I


Click part row for purchase options.


SKUNameWire SizeBody ThreadABC -Wire Depth
mmInchUNFmmInchmmInchmmInch
LSS04-1/4 Lifeline Swage Stud, 3mm, 1/4" Thread 3.0 1/8 1/4 96.0 3 25/32 56.0 2.210 32.0 1 1/4
Handedness:
Units:
LSS04-5/16 Lifeline Swage Stud, 3mm, 5/16" Thread 3.0 1/8 5/16 96.0 3 25/32 61.0 2 13/32 32.0 1 1/4
Handedness:
Units:
LSS05-1/4 Lifeline Swage Stud, 4mm, 1/4" Thread 4.0 5/32 1/4 100.0 3 30/32 56.0 2.210 32.0 1 1/4
Handedness:
Units:
LSS05-5/16 Lifeline Swage Stud, 4mm, 5/16" Thread 4.0 5/32 5/16 108.0 4 1/4 61.0 2 13/32 32.0 1 1/4
Handedness:
Units:
LSS06-1/4 Lifeline Swage Stud, 5mm, 1/4" Thread 5.0 3/16 1/4 100.0 3 30/32 56.0 2.210 32.0 1 1/4
Handedness:
Units:
LSS06-5/16 Lifeline Swage Stud, 5mm, 5/16" Thread 5.0 3/16 5/16 108.0 4 1/4 61.0 2 13/32 32.0 1 1/4
Handedness:
Units:
LSS07-5/16 Lifeline Swage Stud, 5.5mm, 5/16" Thread 5.5 7/32 5/16 120.0 4 23/32 61.0 2 13/32 40.0 1 9/16
Handedness:
Units:
LSS08-5/16 Lifeline Swage Stud, 6mm, 5/16" Thread 6.0 1/4 5/16 129.0 5.000 61.0 2 13/32 53.0 2 3/32
Handedness:
Units:
Part numbers in 1/32"

CAUTION

- If DYFORM or HAMMA wire is used then select fittings for one wire size bigger. These fittings are available on request.

- Maximum Working Loading = 40% of Breaking Strength.
