Allen Head Swage
Available Variations:
Units: Metric-M or Imperial-IClick part row for purchase options.
| SKU | Name | Wire Size | A | B | C | Ø | |||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| mm | Inch | mm | Inch | mm | Inch | mm | Inch | mm | Inch | ||||||
| AHS04 | Allen Head Swage, 3mm / Short | 3.0 | 1/8 | 35.0 | 1 3/8 | 27.0 | 1 2/32 | 9.5 | 3/8 | 6.4 | 0.250 | ||||
| AHS05 | Allen Head Swage, 4mm | 4.0 | 5/32 | 50.0 | 1 31/32 | 39.0 | 1 17/32 | 12.7 | 1/2 | 7.5 | 0.297 | ||||
| AHS06 | Allen Head Swage, 5mm | 5.0 | 5/32 | 50.0 | 1 31/32 | 39.0 | 1 17/32 | 12.7 | 1/2 | 8.8 | 0.345 | ||||
Part numbers in 1/32"
CAUTION
- If DYFORM or HAMMA wire is used then select fittings for one wire size bigger. These fittings are available on request.
- Maximum Working Loading = 40% of Breaking Strength.
