Stemball Swages



Available Variations:

Units: Metric-M or Imperial-I


Click part row for purchase options.


SKUNameWire SizeAppropriate Stem Ball CupA - Wire DepthBØCL
mmInchmm X mmmmInchmmInchmmInchmmInch
SB03 Stemball Swages 2.5mm 2.5 3/32 17 X 6.9 32.0 1 1/4 12.5 1/2 6.4 1/4 61.0 2 13/32
Units:
SB04 Stemball Swages 3mm 3.0 1/8 17 X 6.9 40.0 1 9/16 12.5 1/2 6.4 1/4 61.0 2 13/32
Units:
SB05 Stemball Swages 4mm 4.0 5/32 26 X 11 48.0 1 7/8 15.0 19/32 7.6 0.300 79.0 3.110
Units:
SB06 Stemball Swages 5mm 5.0 3.160 26 X 13 52.0 2.047 20.0 25/32 9.1 0.360 91.5 3 19/32
Units:
SB07 Stemball Swages 5.5mm 5.5 7/32 26 X 16 54.0 2 1/8 21.5 27/32 10.9 7/16 87.0 3 7/16
Units:
SB08 Stemball Swages 6mm 6.0 1/4 26 X 16 64.0 2 17/32 21.5 27/32 12.7 1/2 90.0 3 17/32
Units:
SB09 Stemball Swages 7mm 7.0 9/32 26 X 16 75.0 2 30/32 21.5 27/32 14.2 9/16 96.0 3 25/32
Units:
SB10-1-2 Stemball Swages 8mm With Smaller Head 8.0 5/16 34 X 20 89.0 3 1/2 21.5 27/32 16.2 5/8 127.0 4.000
Units:
SB10-5-8 Stemball Swages 8mm With Larger Head 8.0 5/16 26 X 16 89.0 3 1/2 21.5 27/32 16.2 5/8 127.0 4.000
Units:
SB11 Stemball Swages 9mm 9.0 N/A 34 X 20 0/32 21.5 27/32 0.0 0/32 0/32
Units:
SB12 Stemball Swages 10mm 10.0 3/8 34 X 20 102.0 4.016 21.5 27/32 18.0 23/32 148.0 5 26/32
Units:
Part numbers in 1/32"

CAUTION

- If DYFORM or HAMMA wire is used then select fittings for one wire size bigger. These fittings are available on request.

- Maximum Working Loading = 40% of Breaking Strength.
