Furling Eye Swages



Available Variations:

Units: Metric-M or Imperial-I


Click part row for purchase options.


SKUNameWire SizeABC - Wire Depth
mmInchmmInchmmInchmmInch
FESS03 Furling Eye Swage 2.5mm 2.0 N/A N/A N/A N/A N/A 40.0 1 9/16
Units:
FESS04 Furling Eye Swage 3mm 3.0 1/8 24.0 30/32 14.0 9/16 45.0 1 25/32
Units:
FESS05 Furling Eye Swage 4mm 4.0 5/32 28.0 1 3/32 16.0 5/8 50.0 1 31/32
Units:
FESS06 Furling Eye Swage 5mm 5.0 3/16 30.0 1 3/16 18.0 23/32 60.0 2.362
Units:
FESS07 Furling Eye Swage 5.5mm 5.5 7/32 35.0 1 3/8 18.0 23/32 70.0 2 3/4
Units:
FESS08 Furling Eye Swage 6mm 6.0 1/4 38.0 1 1/2 19.0 3/4 78.0 3 2/32
Units:
FESS09 Furling Eye Swage 7mm 7.0 9/32 38.0 1 1/2 19.0 3/4 80.0 3 5/32
Units:
FESS10 Furling Eye Swage 8mm 8.0 5/16 41.0 1 5/8 20.0 25/32 88.0 3 15/32
Units:
FESS11 Furling Eye Swage 9mm N/A N/A N/A N/A N/A N/A 96.0 3 25/32
Units:
FESS12 Furling Eye Swage 10mm 10.0 3/8 45.0 1 25/32 21.0 26/32 114.0 4 1/2
Units:
FESS14 Furling Eye Swage 11mm 11.0 7/16 45.0 1 25/32 21.0 26/32 124.0 4 7/8
Units:
Part numbers in 1/32"

CAUTION

- If DYFORM or HAMMA wire is used then select fittings for one wire size bigger. These fittings are available on request.

- Maximum Working Loading = 40% of Breaking Strength.
