Allen Head Adjustor
Available Variations:
Handedness: Left Hand-L or Right Hand-RClick part row for purchase options.
| SKU | Name | Body Thread | A | B | C | ØSwage | ||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| UNF | mm | Inch | mm | Inch | mm | Inch | mm | Inch | ||||||
| AHA-1-4FH | Allen Head Adjustor, 1/4" Thread, Round | 1/4 | 50.0 | 1 31/32 | 12.7 | 1/2 | 15.0 | 19/32 | 9.0 | 0.354 | ||||
| AHA-1-4FH | Allen Head Adjustor, 1/4" Thread, Flat | 1/4 | 44.0 | 1 23/32 | 12.7 | 1/2 | 15.0 | 19/32 | 7.9 | 0.312 | ||||
Part numbers in 1/32"
CAUTION
- If DYFORM or HAMMA wire is used then select fittings for one wire size bigger. These fittings are available on request.
- Maximum Working Loading = 40% of Breaking Strength.
